Power Source |
230 V AC, 50 Hz
24 V DC (19.5 - 27 V), M3 screw terminal, distance between barriers: 6.4 mm |
Power Consumption |
195 W (275 VA) at rated power output (AC operation) |
Input |
24 V DC, M3 screw terminal, distance between barriers: 6.4 mm |
Output |
AC operation: 24 V DC ±0.5 V, 5 A (total)
DC operation: Voltage lowering DC input voltage approx. by 1 V
M3 screw terminal, distance between barriers: 6.4 mm |
External Control Input/Output |
Emergency power connection
Emergency power control |
Operating Section |
Power switch |
Display Section |
AC power indicator, DC power indicator |
Operating Temperature |
0℃ to +40℃ |
Operating Humidity |
Under 90% RH (no condensation) |
Finish |
Panel: Aluminum, black, alumite |
Dimensions |
482 (W) × 88.4 (H) × 338.2 (D) mm |
Weight |
8.9 kg |
Accessory |
Power cord (1.8 m) …1, Fuse (6.3 A) …1, Fuse (8 A) …1 |
