| Enclosure Type |
Sealed type |
| Power Handling |
90 W (continuous program/4 Ω)
30 W (continuous pink noise/4 Ω) |
| Rated Input |
12 W (16 Ω, high impedance) |
| Rated Impedance |
4 Ω, 16 Ω
100 V line: 830 Ω (12 W), 1.7 kΩ (6 W), 3.3 kΩ (3 W)
70 V line: 420 Ω (12 W), 830 Ω (6 W), 1.7 kΩ (3 W), 3.3 kΩ (1.5 W) |
| Output Sound Pressure Level |
85 dB (1 W, 1 m) at installation in 1/2 free sound field
(Measured by installing the unit in the center of a wall.) |
| Frequency Response |
120 Hz - 20 kHz |
| Speaker Component |
Low frequency: 8 cm × 5 cm cone-type
High frequency: Balanced dome-type |
| Input Terminal |
Detachable screw terminal, (+)/(-) 2 each (for bridging connection) |
| Usable Cable |
Solid cable, stranded cable: 0.2 - 2.5 m㎡ (AWG No. 24 - 14 equivalent) |
| Finish |
Cover: Fire-resistant ABS resin, white, paint
Punched net: Steel plate, white, paint
Adapter frame: Stainless steel |
| Dimensions |
312 (W) × 126 (H) × 90 (D) mm |
| Weight |
1.5 kg (including adapter frame) |
| Accessory |
Adapter frame ……1, Mounting screw (M4 × 25) ……4, Hole pattern paper ……1 |
| Other Feature |
Enclosure mounting angle: Up to 90 degrees adjustable |
