| Enclosure |
Sealed type |
| Power Handling Capacity |
150 W (Continuous program/8 Ω)
50 W (Continuous pink noise/8 Ω) |
| Rated Input |
30 W (16 Ω, high impedance) |
| Rated Impedance |
8 Ω, 16 Ω
100 V line: 330 Ω (30 W), 670 Ω (15 W), 1.3 kΩ (7.5 W)
70 V line: 170 Ω (30 W), 330 Ω (15 W), 670 Ω (7.5 W), 1.3 kΩ (3.75 W) |
| Sensitivity |
89 dB (1 W, 1 m) at installation in 1/2 free sound field
(Measured by installing the unit in the center of a wall.) |
| Frequency Response |
100 Hz - 20 kHz (-10 dB) at installation in 1/2 free sound field
(Measured by installing the unit in the center
of a wall.) |
| Crossover Frequency |
4 kHz |
| Speaker Component |
Low frequency: 10 cm cone-type × 2
High frequency: 2.5 cm dome-type (neodymium magnet) |
| Input Terminal |
Detachable screw terminal, (+)/(-) 2 each (for bridging connection) |
| Usable Cable |
Solid cable, stranded cable: 0.2 - 2.5 m㎡ (AWG No.24 - 14) |
| Finish |
Enclosure: Fire-resistant ABS resin, black
Front frame: Fire-resistant ABS resin, off-white, paint
Punched net: Steel plate, off-white, paint
Base frame: Steel plate, plating |
| Dimensions |
295 (W) × 318 (H) × 129 (D) mm |
| Weight |
3.3 kg |
| Accessory |
Front grille ……1, Base frame ……1, Electrical box mounting screw ……1 set |
| Usable Electrical Box |
2-gang type |
