Enclosure |
Sealed type |
Power Handling Capacity |
Continuous program: 600 W (single-amp mode)
Low 240 W, High 240 W (bi-amp mode) |
Rated Impedance |
8 Ω (single-amp mode)
Low 8 Ω, High 8 Ω (bi-amp mode) |
Sensitivity |
94 dB (1 W, 1 m) |
Frequency Response |
70 - 20,000 Hz (when using DP-0206* (option)) |
Crossover Frequency |
3,500 Hz |
Directivity Angle |
Horizontal: 90゜, Vertical: 0゜ (within the range of speaker height) |
Speaker Component |
Low frequency: 10 cm cone-type × 8
High frequency: 2.5 cm balanced dome-type × 24 |
Connected Cable |
Direct cable withdrawal from internal speaker: φ8.6 mm,
conductor cross section: 1.25 m㎡, 4-core cable, 3 m |
Operating Temperature |
-10℃ to +50℃ |
Water Protection |
IPX4 |
Finish |
Enclosure: Plywood, white, urethane coating
Front grille: Punched stainless steel (SUS304), white, paint |
Dimensions |
160 (W) × 895 (H) × 255 (D) mm (excluding connected cable) |
Weight |
16 kg |
Accessory |
Bi-amplifier drive rating label …1, Bi-amplifier drive input indication label …1 |
Option |
Matching transformer: MT-S0601, Extension plate: SR-EP4WP,
Wall mounting bracket: SR-WB4WP, Wall tilt bracket: SR-TB4WP,
Protection pad: SR-PP4
Digital processor: DP-0206*
Digital Mixer: D-901
Digital Mixing Processor Unit: D-2008SP |
